Wheat stripe rust monitor

1.Introduction to Wheat stripe rust monitor

Wheat stripe rust monitor is a new type of stripe rust monitoring equipment which integrates meteorological monitoring and intelligent spore capture and microscopic imaging.Wheat stripe rust mainly damages leaves and leaf sheaths, destroys the synthesis of chlorophyll, blocks grain filling, and results in reduced wheat yield or even no harvest.Wheat stripe rust monitor is a new type of stripe rust monitoring equipment that integrates meteorological monitoring and intelligent spore capture microscopy imaging.The system collects the growth environment conditions of wheat planting areas and predicts the incidence of wheat stripe rust based on the system's built-in model.At the same time, the built-in stripe rust spore capture device provides an unmanned and visual verification method for the occurrence of stripe rust by collecting the spore stock and diffusion dynamics of stripe rust.The equipment mainly consists of a meteorological information collection device, a spore capture device, a spore carrying device, an image collection device, a network transmission module, a power supply and a lightning protection system.Realize remote automatic capture of stripe rust spore information, automatic rotation of glass slides, automatic collection, automatic microscopic imaging and photo taking, automatic uploading of picture data, automatic operation and other functions.At the same time, environmental meteorological information and stripe rust disease pictures are uploaded to the designated network platform in real time to form a dynamic comparison database of meteorological environmental information and spore occurrence status, providing a large amount of data support for studying the relationship between stripe rust occurrence trends and meteorology.Provide services for modern agriculture, meet the needs of disease prediction and specimen collection, and prevent and control diseases in a timely manner.

2.Performance characteristics of Wheat stripe rust monitor

1.Meet the safety requirements and technical requirements for fixed spore capture instruments (devices) in the standard GB/T 24689.1-2009 (Mechanical Spore Capture Instruments (Devices) for Plant Protection).

2.Stainless steel spray-coated shell, 15-inch large high-definition capacitive touch screen, Windows operating system, and a good human-computer interaction interface.

3.The 12-megapixel microscopy imaging system with thousand-fold magnification can automatically take high-definition microscopic photos of captured bacterial spores, and the clarity of the captured images can meet the requirements for manual identification of bacterial spore types.

4.The equipment automatically captures bacterial spores 24 hours a day without interruption, automatically takes pictures of the captured bacterial spores, and automatically selects the best pictures to upload.

5.The fully intelligent automatic microscope imaging system can automatically adjust the camera's shooting angle to achieve all-round imaging of the glass slide without blind spots.

6.It can realize automatic operation of the entire process from loading the glass tape, capturing the bacterial spores, microscopic imaging, and recovering the glass tape.

7.Equipped with extra-long special glass carrier tape, which can meet the usage of 600 days.

8.It has multiple working modes, and the automatic running mode, scheduled running mode and debugging running mode can be switched freely.

9.Built-in Beidou/GPS positioning function, device information can be uploaded to the platform in real time, and current device parameters can be viewed on the map.

10.It can monitor air temperature and humidity, atmospheric pressure, wind speed, wind direction, rainfall and other stripe rust monitoring indicators in real time, and predict the incidence through the stripe rust model within the system.

11.The device can be controlled through the platform and APP for operations such as tape feeding, collection, microscopic imaging, and recovery.

12.Remote upgrade and maintenance: The latest programs can be directly and automatically updated remotely, eliminating the need for manual on-site replacement.

13.Multiple data access methods: You can access the platform through PC, view data through mobile APP, and control device actions.

14.Standard 4G communication module, optional 5G communication module.

15.It has a fault self-diagnosis mechanism, and equipment fault information can be reported to the remote server in real time.After-sales personnel can view equipment fault information through the platform.

16.It can be equipped with an intelligent solar power supply management system, which can collect key information such as equipment power consumption, solar power generation, battery voltage, equipment load, and current and upload it to the server (optional).

17.It has flow alarm function.The device can be bound to its traffic card through the platform, and alarm information will be automatically pushed when traffic is abnormal.

3.Technical parameters of Wheat stripe rust monitor

1.Material: GB32080-92 stainless steel;

2.Data transmission method: 4G/5G network (optional), wired network;

3.Power supply voltage: AC 220V±5%;

4.Power: 200W;

5.Timing: 5 time periods can be set;

6.Glass carrier tape: Length: 150M Width: 0.025M, can meet the usage of 600 days;

7.Wind speed of air collection port: 0.3～5 m/s;

8.Insulation resistance: ≥2.5MΩ;

9.Air temperature: -30~80℃, accuracy: ±0.3℃

10.Air humidity: 0~100%, accuracy: ±3%

11.Wind speed: 0～30m/s, accuracy: ±0.1m/s

12.Wind direction: 0-359° Accuracy: ±1°

13.Rainfall: 0～4mm/min, error: ±0.1mm

14.Atmospheric pressure: 0-1100hpa, accuracy: 0.1hpa
