Locust online monitoring station

1.Product features of Locust online monitoring station

Locust online monitoring station can collect, analyze and calculate locust population density, instar characteristics and other information through light and sex lure.Locust online monitoring station is mainly suitable for locust breeding areas.It can collect, analyze and calculate locust population density, age characteristics and other information through light and sexual induction.It supports time control function, automatic photography, automatic identification, and can identify common forest and grass.locust.It can collect and analyze grassland locust information at fixed monitoring points, and transmit the data back to the monitoring and early warning center in real time.

2.Performance characteristics of Locust online monitoring station

1.Designed with stainless steel spray-coated shell.

2.Integrate light lure, sexual lure, machine vision, Internet of Things technology, and big data technology to realize online monitoring of locusts.

3.Through two methods: locust-specific attractant induction and double light induction, the double lights can be interchanged at regular intervals.

4.It is composed of an integrated control system, a 20 million high-definition camera system, and an insect collection platform, which can clearly collect photos of locusts in static and moving states.

5.Supports time control function, automatic photo taking, automatic identification, and can identify common forest and grass locusts.

6.Through data collection, analysis and calculation, the locust population density and age characteristics can be obtained.

7.Remote real-time monitoring and data alarm can be done through app or web client.

8.Equipped with a GPS positioning system, which can directly upload location information to the server.

9.Data transmission can be achieved through a variety of wireless networks (3G/4G/5G), and data supports local storage.

10.The overall design is rainproof and can work normally even in rainy days.

3.Technical parameters of Locust online monitoring station

1.Working voltage: DC12V

2.Dual-light insect trap light source: yellow light 580-620nm, red light wavelength 640-680nm

3.Solar panel power: ≥40W

4.Battery: DC12/20AH lithium battery

5.Power consumption: standby state ≤10W

6.Design life ≥10 years
