Wireless Tilt Sensor

Wireless Tilt Sensor

Model:FT-QJ1
Brand:fengtu
Wireless Tilt Sensor is a standard industry triaxial tilt meter that determines the tilt state of the monitored object by detecting the tilt Angle in the environment in use....

1. Wireless Tilt Sensor Product Introduction

Wireless Tilt Sensor is a standard industry triaxial tilt meter that determines the tilt state of the monitored object by detecting the tilt Angle in the environment in use.Our company designs and develops inclinometers based on the principles of high precision, low power consumption, stability and reliability.It can be combined with intelligent gateways, alarm equipment and the Internet of Things platform to form a closed-loop system for geological disaster hazard points, self-monitoring, self-analysis, and self-alarm.It is suitable for monitoring fields such as geological disasters, geotechnical engineering, construction engineering, transportation, water conservancy, and municipal administration.Real-time monitoring of high-frequency vibration of structures and slight tilt changes of geological disaster bodies.

2.Wireless Tilt Sensor product features

(1) High integration: Integrated MEMS acceleration module to realize three-axis acceleration and three-axis inclination observation functions, while collecting ambient temperature for temperature compensation;

(2) Multi-communication: Integrate 2/4G full network public network communication, support NB-IoT narrowband Internet of Things communication, and support LoRa local ad hoc network communication to realize local networking of monitoring equipment, regional release of early warning information, and remote monitoring data Transmission and equipment remote control;

(3) Low power consumption: Adhering to the design concept of high integration and low power consumption, the integrated design of sensing, collection and communication is realized.The standby performance meets the needs of long-term use in the field.It has the characteristics of convenient installation and is especially suitable for emergency monitoring and deployment;

(4) High precision: Using on-site redundant observations, based on a priori errors and measured errors, embedded edge calculations and data filtering and data cleaning algorithms can achieve gross error elimination and anomaly detection to ensure the reliability of monitoring data and meet the requirements Requirements of relevant technical standards;

3.Wireless Tilt Sensor technical parameters

Sensor performanceinclinationMeasuring range±90°
AccuracyAccuracy: ±0.001/±0.005/±0.01 optional
accelerationMeasuring range±3g
Accuracy0.5mg
working conditionsWorking voltage3.7V~4.2V
Rated power consumption<120mA/3.7V
working temperature-40℃~85℃
Working humidity95%RH no condensation
Communication performancecommunication network2~4GPRS/NB-IOT/LORA
Collection interval1~50Hz high frequency or 0~7200s low frequency can be set as needed
Upload strategyScheduled upload + event-triggered upload
interactive controlsupport
