Pipe wind speed sensor

Pipe wind speed sensor

Model:FT-GFS1
Brand:fengtu
Pipe wind speed sensor is suitable for gas measurement, and has real-time display and other functions, which is convenient for users to monitor and control pipe wind speed....

Device name: Pipe wind speed sensor

Pipe wind speed sensor is suitable for gas measurement, and has real-time display and other functions, which is convenient for users to monitor and control pipe wind speed.

Function description: Designed for pipe wind speed measurement, the independently developed high-precision wind speed measurement unit is responsive and can quickly and accurately measure tiny wind speeds, with good stability, small drift and high accuracy. The transmitter can also calculate the real-time air volume value based on the measured pipe cross-sectional area.

Detection principle: The hot-wire balance principle is used to measure wind speed. The response speed is fast and the starting wind speed is small.

Calibration method: Adopt the full-scale secondary calibration method independently developed by the company, which has good linearity and high accuracy.

Wiring method: The terminal block adopts military-grade spring-type screw-free terminals, which can be connected by pressing and plugging in. You can quickly connect the wires even if there is no screwdriver on site, and can adapt to wire diameters of 0.3~2.0mm.

Pipe wind speed sensor installation precautions:

1. Open-hole flange installation, using high-quality silicone sealing ring, small air leakage and durable.

2. Note that it needs to be installed on the side or below of the pipe, and cannot be installed from top to bottom.

3. First drill a hole with a diameter of 20mm in the ventilation duct, insert the air duct into the hole, and adjust the direction of the device so that the arrow direction of the device is consistent with the direction of the wind speed (the direction of the wind). You can adjust the flange by adjusting the direction of the flange. Position controls the height of the device.

Pipe wind speed sensor measurement elements:

1. Real-time pipeline wind speed

2. RS485 type optional air volume value in the duct

Signal output: RS485, 4-20ma, 0-5v, 0-10v

Pipe wind speed sensor parameter modification:

1. The device address and baud rate can be changed through the 485 command, and the pipeline cross-sectional area can be set.

Model 2.485 can provide professional configuration tools to configure device parameters.

3.485 model can adjust the 485 slave station through hardware DIP switch

Probe wire length: The default wire length is 1m, it can be long or short, the longest can be 100m but there needs to be no interference around the wire body.

Pipe wind speed sensor device displays:

1. Optional organic light-emitting display, OLED screen with wider viewing angle, self-illumination and low power consumption.

Model 2.485 can display the current wind speed and related air volume in turn.

3. The analog type can display the current range and current wind speed.

Power supply mode: 10-30V DC

Maximum power consumption: 0.5W

Measuring medium: air, nitrogen, oil fume exhaust gas

Accuracy: The accuracy of the measuring range 0~10m/s is ±(0.1+2%FS); the accuracy of the measuring range 0~15m/s, 0~20m/s, 0~30m/s is ±(0.2+2%FS) m/ s;

Circuit operating temperature: -10℃~+50℃

Wind speed display resolution: 0.1m/s

Response time: 2S

Long-term stability: ≤0.1m/s/year
