1.Solar simulation systems product overview
Solar simulation systems is an experimental device for the study of photocatalytic reactions, the main purpose of which is to simulate the radiation properties of sunlight.Solar simulation systems provide an environment close to natural daylight, achieving 24-hour uninterrupted light regardless of factors such as environment, climate, and time.It is widely used in solar cell characteristic testing, dye-sensitized cells (DSSC), perovskite cells (PSC), optoelectronic material characteristic testing, biochemistry-related testing, photocatalytic degradation acceleration research, skin cosmetics testing and environmental research, etc.
2.Product features of Solar simulation systems
1.Advanced intelligent adjustment of irradiation intensity, which can adjust the irradiation intensity in time according to the experimental requirements and experimental stage settings.
2.The direction of light is vertically up and down, horizontally left and right.Four directions of illumination.
3.The irradiation area can be customized according to needs, ranging from 1 to 100 square meters.
4.Three intelligent controls: It can be controlled manually, it can be controlled through the client, and it can be controlled through the cloud.
5.Fan power-off delay function.After shutdown, the equipment cooling system delays power-off processing, eliminating the need for manual intervention, saving working time and extending the service life of the equipment.
6.Super long service life: The life of the bulbs is more than 2,000 hours.
3.Technical indicators of Solar simulation systems
name | Technical specifications |
Irradiation area | 1 to 100 square meters, customized according to experimental requirements |
Light source type | Long arc pulse xenon lamp |
light unevenness | ±10% |
light instability | ±10% |
Spectral distribution | Class B |
Control method | Manual, client and cloud control |
Cooling method | Delayed air cooling |
working environment | Ambient temperature: -20~40℃, relative humidity: ≦70% |
Power supply method | AC380V, three-phase five-wire system input |
Lamp life | 2000 hours |
Light direction | Vertically up and down, horizontally left and right |
Radiation intensity | 400~1800W/m2 |
Light source output | parallel light irradiation |
