Soil NPK Sensor

Soil NPK Sensor

Model:FT-NPK
Brand:fengtu
Soil NPK Sensor is used to measure the content of nitrogen (n), phosphorus (p) and potassium (k) in soil. It is widely used in rice field, greenhouse planting, rice, flowers and soil research....

1. Soil NPK Sensor Product Overview

Soil NPK Sensor is used to measure the content of nitrogen (n), phosphorus (p) and potassium (k) in soil. It is widely used in rice field, greenhouse planting, rice, flowers and soil research.Soil NPK Sensor is suitable for detecting the content of nitrogen, phosphorus and potassium in the soil.By detecting the content of nitrogen, phosphorus and potassium in the soil, the fertility of the soil can be judged, thereby facilitating the systematic assessment of soil conditions.It can be buried in the soil for a long time, is resistant to long-term electrolysis, corrosion resistance, vacuum potting, and is completely waterproof.

The sensor is widely used in soil nitrogen, phosphorus and potassium detection, precision agriculture, forestry, soil research, geological exploration, plant cultivation and other fields.

2.Functional features of Soil NPK Sensor

1.Low threshold, few steps, fast measurement, no reagents required, and no limit on the number of tests.

2.High measurement accuracy, fast response speed and good interchangeability.

3.The electrodes are made of specially treated alloy materials, which can withstand strong external impacts and are not easily damaged.

4.Completely sealed, resistant to acid and alkali corrosion, and can be buried in the soil for long-term dynamic testing.

5.The probe insertion design ensures accurate measurement and reliable performance.

3.Soil NPK Sensor technical parameters

DC power supply (default)DC 5-30V
Maximum power consumption≤0.15W (@12V DC, 25℃)
working temperature0℃~55℃
Nitrogen, phosphorus and potassium parametersMeasuring range1-1999 mg/kg(mg/L)
resolution1 mg/kg(mg/L)
response time<1S
Protection levelIP68
Probe materialStainless steel
sealing materialBlack flame retardant epoxy resin
Default cable length2 meters, cable length can be customized as required
Overall dimensions45*15*123mm
Output signalRS485(Modbus protocol)
