Wheat midge monitor

1.Wheat midge monitor product description

Wheat midge monitor is based on the principle that fluke is sensitive to certain colors. The device can adjust the color plate, rotate, take photos and upload data.Wheat midge larvae lurk in the wheat hulls and suck the wheat grains that are being filled, reducing the thousand-kernel weight and resulting in a reduction in yield.The Wheat midge monitor is developed based on the principle that midges are sensitive to specific colors.The device integrates the functions of automatically adjusting the height of the color plate, automatic rotation, automatic photography, and automatic data upload.It also performs integrated monitoring of meteorological data to study midges.The relationship between the outbreak and meteorology.

2.Performance characteristics of Wheat midge monitor

1.Adopt light, electricity, numerical control technology and automatic control.

2.Color 7-inch Chinese LCD capacitive touch screen operation; can be set and controlled by time periods, and can take pictures automatically or manually; Android system intelligent control, environmental temperature, humidity and time display.

3.Equipped with 1200W pixel image acquisition equipment, the insect status on the color plate can be collected in real time through the camera, and the clarity of the captured image can meet the requirements for manual identification of insect species.

4.Equipped with a liftable insect trapping device that can automatically or manually raise and lower the insect trapping height of the color plate.

5.Various parameters of the instrument can be remotely configured through the server to facilitate maintenance and management.

6.Built-in GPS or Beidou positioning function, you can view device site and other data on the map.

7.Power supply mode: solar power, solar energy and battery are used together (DC type).

8.Equipped with various environmental sensors such as wind speed, wind direction, air temperature, air humidity, and rainfall.

9.Network mode: A variety of networking methods, 4G\WIFI\wired, can be selected at will, and can be managed online anytime and anywhere.

10.Device data can be viewed through PC, APP, WeChat and other methods.

3.Wheat midge monitor technical parameters

1.Power supply: solar panel power: 60W, battery specification: 12V 24AH

2.Power consumption: ≤50W

3.Insect attracting device: color plate

4.Insulation resistance: ≥2.5 MΩ
