Well Level Monitoring

1. Well Level Monitoring Product Introduction

Well Level Monitoring is used to automatically monitor the dynamic change of groundwater level and detect the abnormal situation of groundwater level in time.DSW4Well Level Monitoring is widely used in deep groundwater well water level measurement, mine deep well water level measurement, and geothermal well water level measurement.Its measurement range can reach 100 meters, 200 meters, 300 meters, and 400 meters.It is mainly based on the built-in sealing sensor chip of the ultra-strong and high-pressure resistant high underground deep well water level online monitoring system, one-piece structure, and triple lightning protection technology.The signal transmission uses tensile-resistant steel wire cables to ensure that the measurement signals can be output and displayed in real-time, with high precision and stability.

Well Level Monitoring uses water pressure sensitive integrated components to make sensor probes for deep well water level measuring instruments based on the hydrostatic principle that pressure is proportional to water depth.When the sensor probe is fixed at a certain measuring point underwater, the height of the water column pressure above the measuring point increases.By measuring the elevation of this point, you can indirectly measure the water level (the distance from the water surface to the wellhead); what you can directly measure is the actual liquid level in the deep well above the sensor probe.

2.Well Level Monitoring Product Features

1.Reverse polarity protection and instantaneous overcurrent and overvoltage protection meet EMI protection requirements;

2.It adopts high-quality air-conducting cables and can be soaked in water all year round;

3.Strong overload and anti-interference ability, economical, practical and stable;

4.The core automatic correction algorithm is adopted to effectively prevent numerical fluctuations caused by water surface fluctuations;

5.The slope-type liquid diversion hole can effectively prevent the entry of silt and impurities and also prevent impact.

6.Diffused silicon piezoresistive sensor;

7.The probe is inserted into the measurement method, and the installation is simple and convenient;

8.Multiple protection structure design, high protection ability;

9.Use anti-corrosion stainless steel materials, suitable for various occasions;

10.RS485 signal output, the longest communication distance can reach 2000 meters;

11.10~30V wide power supply voltage input.

12.The inlaid design of the solar panel top cover improves the photoelectric conversion efficiency and increases the wind resistance level.

13.Charge controller: MPPT automatic power point tracking, efficiency increased by 20%

14.SMS alarm, send SMS to the designated mobile phone after exceeding the limit

15.ABS material protective box, corrosion-resistant, anti-oxidation, waterproof grade IP66

3.Main technical parameters of Well Level Monitoring

4.Introduction to Well Level Monitoring PC software

1.PC stand-alone version of data receiving, storage, viewing and analysis software

2.Support serial port data reception, processing and display

3.Support json string, modbus485 and other communication methods

4.The storage time can be set by oneself, and the collection time can be set by oneself in the modbus485 collection mode.

5.Support self-service adding, deleting, and modifying protocols, names, icons, etc.of monitoring parameters.

6.Support data post-processing function

7.Support external running of javascript scripts

5.Introduction to Well Level Monitoring Android APP

1.Android stand-alone version of data receiving, storage, viewing and analysis software

2.Support Bluetooth data reception

3.After the mobile phone is asleep, the software receives and processes it in the background

4.JSON data automatically adds devices, and modbus devices support scanning QR codes to add devices.

5.Supports historical data viewing, analysis, and table export, and supports curve display and single data point viewing.

6.Support data post-processing function

7.Support external running of javascript scripts

6.Introduction to Well Level Monitoring Cloud Platform

1.CS architecture software platform supports direct observation on mobile phones and PC browsers without the need to install additional software.

2.Support multiple accounts and multiple devices to log in

3.Support real-time data display and historical data display dashboard

4.Cloud servers and cloud data storage are stable and reliable, easy to expand, and load balanced.

5.Support SMS alarm and threshold setting

6.Support map display and view device information.

7.Support data curve analysis

8.Support data export table format

9.Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.

10.Support data post-processing function

11.Support external running of javascript scripts
